AM160-YYH660
AM160-YYH660 is the large-template variant of the AM160 360° fingerprint module family — the 1,000-capacity class configuration for the door that has 300 people to look after, on the family's ⌀14–16 mm platform with UART and sub-0.3 s matching. MOQ is 1 pc; free SDK and 48h FAE are standard.
Series reference image — AM160-YYH860
Key specifications
| Function | 360° fingerprint enrollment and 1:1 / 1:N verification on module |
|---|---|
| Capture type | AM160 family, ⌀14–16 mm class, 360° rotation-tolerant (family class) |
| Template capacity | 1,000-capacity class — the family's large-template allocation |
| Match speed | <0.3 s (family class) |
| Host interface | UART |
| Target applications | High-end locks, event venues, payment-adjacent readers |
| Marking | AM160-YYH660 (large-template variant) |
Full specification
| Parameter | Value | Note |
|---|---|---|
| Product family | AM160-series 360° fingerprint module | ⌀14–16 mm family |
| Positioning | Large-template variant | 1,000-capacity class |
| Match speed | <0.3 s | Family class |
| Template capacity | 1,000-capacity class | Top tier of family range |
| Rotation tolerance | 360° capture | Family class |
| Host interface | UART | SDK examples included |
| Operating temperature | −40~85°C | Family class |
| Liveness | Semiconductor-based checks | Family class |
| Volume lead time | 10–25 days, orders under 5,000 units | Company standard |
Enroll times and record growth depend on the host MCU — the FAE team validates your roster pattern within 48h.
A roster-heavy door needs the roster slot.
Headquarters doors and residence towers run rosters in the thousands — a template budget that ends at 200 is a hotline that starts in year two. The large-template variant answers with the family's 1,000-capacity tier:
- 1,000-capacity class covers an entire roster class — staff, maintenance, and visitor records kept on one door (family tier).
- Template hygiene grows with the roster — SDK export/import keeps enrollments de-duplicated without re-registration.
- Sub-0.3 s family match keeps the high-capacity door feeling like the 10-person door next to it.
Where the module listing pays for the lock.
POS and kiosk vendors in the payment-adjacent tier pair the large-template module with their own reader — a big roster is a feature they can list on the spec sheet, not an unpublished limit.
- −40~85°C family-class rating survives the touchline of a busy lobby fixture.
- Free SDK includes 1:N demo tuned for roster-sized enroll sets.
- MOQ 1 pc for the demo fixture; 10–25 day lead under 5,000 units once the spec sheet is printed.
AM160-YYH660 FAQs
Yes — 1 pc is the MOQ; the FAE team pre-validates your enroll count against the 1,000-capacity tier within 48h.
The 360° algorithm and SDK are free, with a 1:N demo tuned for large enroll sets over UART.
It covers the family's large-template tier; bigger sites split by door and sync templates via the SDK's 1:1 export — or move to the access terminal per door.
Size the roster, then spec the module.
Send the expected enroll count — get the YYH660 capacity check, datasheet and 1-pc offer within 48h.
