AM160-YYH32L
AM160-YYH32L is the general variant of the AM160 360° fingerprint module family — a ⌀14 mm capture module with a UART host interface, built to be the default entry in a door OEM's BOM. MOQ is 1 pc; the free SDK and a 48h FAE response cover schematic-level turn-up.
Series reference image — AM160-YYH860
Key specifications
| Function | 360° fingerprint enrollment and 1:1 / 1:N verification on module |
|---|---|
| Capture type | ⌀14 mm class, 360° rotation-tolerant capture (family class) |
| Match speed | <0.3 s (family class) |
| Template capacity | 100–1,000 templates (family class) |
| Host interface | UART |
| Target applications | B2B door OEM lines, straight-board and slider locks |
| Marking | AM160-YYH32L (⌀14 mm general variant) |
Full specification
| Parameter | Value | Note |
|---|---|---|
| Product family | AM160-series 360° fingerprint module | ⌀14–16 mm family |
| Capture diameter | ⌀14 mm | General variant positioning |
| Match speed | <0.3 s | Family class |
| Template capacity | 100–1,000 | Family class, per-variant allocation |
| Rotation tolerance | 360° capture | Family class |
| Host interface | UART | SDK examples included |
| Operating temperature | −40~85°C | Family class |
| Liveness | Semiconductor-based checks | Family class |
| Volume lead time | 10–25 days, orders under 5,000 units | Company standard |
Board-level values vary with the host MCU wiring — the FAE team validates module parameters against your lock schematic within 48h.
Default on the BOM, not an experiment.
Door OEMs bought into a 45 M-unit smart-lock year in 2025, with China at about 55% of output — the general variant is the one that gets quoted first and stays in the drawing. That is the YYH32L slot:
- ⌀14 mm class mounting maps to the existing stamping in straight-board lock bodies, no retool.
- One UART, three firmware options — the SDK's variant table covers the enclosure, not a per-model rewrite.
- 1-pc MOQ makes the engineering sample the same part number the line will run.
Turn-up without a firmware campaign.
Volume builders hate a turn-up that eats a sprint — the free SDK ships enroll, verify and threshold demos for the UART host path, so the bench produces a demo in a day, not a month.
- −40~85°C family-class rating covers the unheated edge of a door line's test fixture.
- Burn-in and aging flows follow the model standard, with unit-level test pass per part.
- 2-year warranty from the 1-pc sample through the 5,000-unit replenishment.
AM160-YYH32L FAQs
Yes — 1 pc is the MOQ; send the lock drawing and the FAE team confirms the ⌀14 mm mounting and UART wiring within 48h.
The 360° matching algorithm and SDK ship free, with enroll and verify demos for the UART host path.
The AM160 family spans 100–1,000 templates; the YYH32L general allocation is configured via the SDK to match your lock's user class.
Put the general variant in your drawing.
Send the BOM context — get the YYH32L datasheet, SDK links and 1-pc offer inside one 48h FAE response.
