X30
The X30 is the family-top fixed module of the X series — the flagship fixed position for the highest standard installations, where one module program deliberately covers the rooms where the scanning makes or breaks the day.
Key specifications
| Function | Flagship fixed 2D capture for highest-standard installations |
|---|---|
| Imaging engine | CMOS imager, 0.5–0.75 MP class (family standard) |
| Symbologies | All 1D plus QR, DataMatrix, PDF417, Aztec, China Post codes |
| Precision | 4 mil minimum element width class |
| Read range | 0–80 cm class (family-class value) |
| Mounting | Flagship fixed-mount form — top-tier geometry |
| Host interfaces | USB HID / CDC, RS232 |
| Target applications | Reference installations, medical-adjacent fixtures, flagship docks |
Full specification
| Parameter | Value | Note |
|---|---|---|
| Product family | EMS Biometric X-series fixed module | Family top |
| Imaging sensor | CMOS, 0.5–0.75 MP class | Family standard |
| Resolution | 4 mil class | Per-model in datasheet |
| Symbologies | EAN/UPC, Code 39/93/128, GS1-128, ITF-14, Codabar, QR, DataMatrix, PDF417, Aztec, China Post codes | Full 2D set |
| Read range | 0–80 cm class | Family-class; per-model curve in datasheet |
| Host interfaces | USB + RS232 | Both standard |
| Control | Serial command set via SDK | Trigger and result flow documented |
| Mounting | Flagship fixed-mount form | Bracket drawings in datasheet and SDK pack |
| Operating temperature | Commercial-to-industrial class | Mounting-dependent; confirm per model |
| Supply terms | MOQ 1 pc · sample 1–3 days · production 10–25 days (under 5,000 pcs) | EMS standard terms |
| Warranty | 2 years | From first unit |
Family-class values shown — exact per-model figures in the datasheet; the FAE team verifies flagship duty within 48h.
Standardized automation rooms buy one module, deliberately.
Automation rooms in large pharmacies run days without a human at the window: the robot moves, the packs register, and the stock decisions ride on each decode. The X30 is the flagship fixed module for those rooms — the family-top position chosen when the room's program gets written once and the hardware list is the conclusion:
- Run under program, not supervision — the serial command set lets the room's flow engine drive every trigger; the verify step is part of the software, and the module is the enforcement point.
- Serialized pack discipline, at the machine's pace — DataMatrix on serialized cartons decodes at full 2D coverage on the family-top profile, keeping verification inside the picking cycle.
- The part number of the room — one flagship SKU, one bracket plan, one spares line; the 2-year warranty is written against a machine that runs 24/7, which is precisely the X30's brief.
X30 FAQs
When the installation is the standard, not the experiment: both share the engine family, but X30 is the family-top position — chosen for rooms whose hardware list must close the argument once, instead of a per-slot debate.
The duty position is built for continuous stations; the datasheet holds the power and duty-cycle detail and the FAE team validates your actual machine cadence in the first site call.
Yes — serial control plus the SDK's flow examples target exactly that; send your flow engine's interface file and the FAE team confirms the fit within 48h.
Let an engineer verify your X30 rooms.
Send your room flow and interface files — get a duty plan, updated datasheet and flagship pricing within 48h.
