X6
The X6 is the fixed-family module of the X series — the standard-position fixed-mount 2D engine for cell stations and line fixtures, and the unit most plants standardize on when they standardize at all.
Key specifications
| Function | Reference-position fixed 2D capture for cell stations |
|---|---|
| Imaging engine | CMOS imager, 0.5–0.75 MP class (family standard) |
| Symbologies | All 1D plus QR, DataMatrix, PDF417, Aztec, China Post codes |
| Precision | 4 mil minimum element width class |
| Read range | 0–80 cm class (family-class value) |
| Mounting | Fixed-mount form — standard cell fixture geometry |
| Host interfaces | USB HID / CDC, RS232 |
| Target applications | Line cells, fixture stations, dock-side fixed positions |
Full specification
| Parameter | Value | Note |
|---|---|---|
| Product family | EMS Biometric X-series fixed module | Family standard |
| Imaging sensor | CMOS, 0.5–0.75 MP class | Family standard |
| Resolution | 4 mil class | Per-model in datasheet |
| Symbologies | EAN/UPC, Code 39/93/128, GS1-128, ITF-14, Codabar, QR, DataMatrix, PDF417, Aztec, China Post codes | Full 2D set |
| Read range | 0–80 cm class | Family-class; per-model curve in datasheet |
| Host interfaces | USB + RS232 | Both standard |
| Mounting | Fixed-mount form | Bracket drawings in datasheet and SDK pack |
| Operating temperature | Commercial-to-industrial class | Mounting-dependent; confirm per model |
| Supply terms | MOQ 1 pc · sample 1–3 days · production 10–25 days (under 5,000 pcs) | EMS standard terms |
| Warranty | 2 years | From first unit |
Family-class values shown — exact per-model figures in the datasheet; the FAE team verifies station fit within 48h.
Cells need their own read; the people need their own hands.
Assembly cells are where traceability gets honest: each tray's serial at the fixture, each part's matrix at the station — and a worker with a gun in one hand is a worker with one-hand working. The X6 fixed module removes that trade: the fixture's own reader at the cell's own read window, the full 2D set where the trays pass:
- The cell's rhythm, not the worker's detour — trays pass across the X6's window in the flow of the cell; no reach, no pick-up, no return trip.
- Full 2D on line parts — the DataMatrix on new parts and the Code 128 on printed trays both decode at the fixture, which keeps one record per cell instead of per gun.
- Audit-ready by equipment design — fixed station logging with the free SDK writes the cell's sequence; the 2-year warranty backs a fixture that runs in the line's rhythm.
X6 FAQs
Position: the X6 is the standard-format fixed module the X-series geometry hangs around; most plant fixtures start at the X6 and move up to the performer only when the duty figure says so.
USB HID works with the cell's existing terminal; RS232 mode plus the free SDK covers a small controller at the fixture when the cell has no PC to spare.
Fixed-mounts read best with a known geometry; the 4 mil class still leaves the window generous — the FAE team sets the mount angle in 48h against your tray's passing line.
Let an engineer verify your X6 cells.
Send your cell drawings and tray flow — get a mount plan, updated datasheet and sample offer within 48h.
