S10
The S10 is the entry 1D scanner of the S series — a wired laser line built for simple point-and-scan work, supplied from one piece (MOQ 1 pc) with a free SDK, datasheet package and 48h FAE engineering contact.
Key specifications
| Function | Entry 1D scanning for receipt, shelf and queue workflows |
|---|---|
| Scan engine | 1D laser engine — S-series entry configuration |
| Symbologies | EAN/UPC, Code 39/93/128, GS1-128, ITF-14, Codabar, China Post codes (family standard) |
| Precision | 4 mil minimum element width class |
| Read range | 0–80 cm class (family-class value) |
| Host interfaces | USB HID / CDC, RS232 — wiring guides supplied |
| Trigger | Manual trigger, standard gun grip |
| Target applications | Mailroom sign-off, campus cash desks, small retail back counters |
Full specification
| Parameter | Value | Note |
|---|---|---|
| Product family | EMS Biometric S-series handheld 1D | Entry tier of the S line |
| Scan engine | Laser-based 1D engine | Family-standard configuration |
| Resolution | 4 mil class | Per-model spot size in datasheet |
| Symbologies | EAN/UPC, Code 39/93/128, GS1-128, ITF-14, Codabar, China Post codes | 1D set only — see S20 for 2D |
| Read range | 0–80 cm class | Family-class; trigger curve per model |
| Host interfaces | USB + RS232 | Both standard, documented |
| Wireless | Wired unit | Wireless sibling on request |
| Operating temperature | Indoor commercial class | See W-series for industrial range |
| Supply terms | MOQ 1 pc · sample 1–3 days · production 10–25 days (under 5,000 pcs) | EMS standard terms |
| Customization | Logo silk-screen, packaging, cable marking per project | OEM order-based |
| Warranty | 2 years | From first unit |
Family-class values shown — the datasheet lists exact per-model figures; the FAE team confirms your configuration within 48h.
Receipts, before the day ends.
Campus mailrooms, plant gatehouses and reception desks all share the same broken rhythm: a parcel arrives, someone reads a 12-digit code out loud, and it is written into a notebook that the evening shift never hears about. The S10 is the machine we point at that problem — one hand, one squeeze, one code in the log:
- Sign-off without a screen — the S10's laser line is faster to aim than a phone camera on a cold, wet box, and it accepts the worn EAN/UPC labels that gatehouse parcels usually carry.
- Logs the shift, not the guess — USB HID output drops the code straight into the existing reception PC or a handheld checkout app, no driver or middleware to negotiate.
- Built to be secondhand — MOQ 1 pc means a gatehouse pilot costs almost nothing; the 2-year warranty and 48h FAE line keep a single-scanner site from feeling abandoned.
Same bracket, same line
S10 FAQs
Yes — 1 pc is the MOQ. Sample ships in 1–3 days with the datasheet, cable pinout and a setup routine; the 48h FAE line covers your PC-side integration.
It reads retail EAN/UPC labels down to the 4 mil class; heavily scuffed or torn labels should be regenerated in the store system — every scanner hits a physical limit there.
Yes — both interfaces are standard on the unit; swap the cable and confirm the baud/format setting, the FAE team verifies your terminal within 48h.
Let an engineer verify your S10 pilot.
Send your receipt workflow and terminal model — get a scan-range check, updated datasheet and sample offer within 48h.
