W1
The W1 is the 1D high-speed CCD scanner of the W series — a high-cadence red-line CCD that reads conveyor-fed 1D labels faster than hand-operated units settle, for the feeding stations of a wholesale line.
Key specifications
| Function | High-cadence 1D capture at belt and feed-line work points |
|---|---|
| Scan engine | High-speed CCD line, 1,500-pixel class, red illumination |
| Cadence profile | Fast-family CCD tuning — consecutive reads without settle delay |
| Symbologies | EAN/UPC, Code 39/93/128, GS1-128, ITF-14, Codabar, China Post codes |
| Precision | 4 mil minimum element width class |
| Read range | 0–80 cm class (family-class value) |
| Host interfaces | USB HID / CDC, RS232 |
| Target applications | Feed-line checkpoints, wholesale patching, belt-side verification |
Full specification
| Parameter | Value | Note |
|---|---|---|
| Product family | EMS Biometric W-series handheld CCD | High-speed 1D line |
| Capture sensor | 1,500-pixel CCD line, high-speed readout | Family-standard; per-model cadence in datasheet |
| Resolution | 4 mil class | Per-model in datasheet |
| Symbologies | EAN/UPC, Code 39/93/128, GS1-128, ITF-14, Codabar, China Post codes | Dense 1D set |
| Read range | 0–80 cm class | Family-class; per-model curve on request |
| Host interfaces | USB + RS232 | Both standard |
| Wireless | Wired unit | Wireless industrial is W2L/W11W |
| Operating temperature | Industrial temperature-class design | Wider range than commercial units |
| Supply terms | MOQ 1 pc · sample 1–3 days · production 10–25 days (under 5,000 pcs) | EMS standard terms |
| Warranty | 2 years | From first unit |
Family-class values shown — exact per-model figures in the datasheet; the FAE team measures cadence against your belt speed within 48h.
The feeding aisle is the first store the customer never sees.
Unmanned retail's supply is only as clean as its feed line: cartons arrive on a belt, and someone's hand must read every label before the shelf decides. That hand is the bottleneck — and a standard scanner forces the hand to pause for each read. The W1's high-speed CCD line keeps up with the belt rhythm instead:
- Cadence the belt can live with — consecutive reads without settle delay across the fast 1D labels most incoming cartons carry.
- Red light for the crates and the shade — the high-speed CCD reads shelf-shadowed and slightly scuffed labels where a slower laser line burns a fraction of a second it doesn't have.
- One station, learned once — USB HID to the receiving PC, the same unit for re-tickets and returns; the 2-year warranty matches the belt's schedule, not yours.
W1 FAQs
The high-speed CCD line is designed for consecutive at-feed reads — the honest answer is belt-speed dependent, and the FAE team measures your actual cadence with one sample before you commit the station.
Wearables and mirror assemblies drift at high cadence; a solid-state CCD line is the engineering choice for continuous feed work, and it reads scuffed labels better at close range.
The W1 is a handheld-bodied unit in this configuration; fully fixed solutions are the X-series modules — the FAE team classifies your station for one or the other.
Let an engineer verify your W1 feed stations.
Send your belt speed and labels — get a cadence measurement, updated datasheet and sample offer within 48h.
