R52
The R52 is the family-top presentation unit of the R series — the highest hands-free 2D window of the presentation line, chosen for dense-bay and high-density windows where the read rate itself is the throughput.
Key specifications
| Function | Family-top hands-free 2D capture at dense-bay windows |
|---|---|
| Imaging engine | CMOS imager, 0.5–0.75 MP class (family standard) |
| Symbologies | All 1D plus QR, DataMatrix, PDF417, Aztec, China Post codes |
| Precision | 4 mil minimum element width class |
| Read range | Hands-free 0–80 cm class (family-class value) |
| Host interfaces | USB HID / CDC, RS232 |
| Duty profile | Family-top tuning — the fullest continuous present rhythm of the line |
| Target applications | Bay gates, dense sorting windows, high-flow verification stations |
Full specification
| Parameter | Value | Note |
|---|---|---|
| Product family | EMS Biometric R-series presentation scanner | Family-top tier |
| Imaging sensor | CMOS, 0.5–0.75 MP class | Family standard |
| Resolution | 4 mil class | Per-model in datasheet |
| Symbologies | EAN/UPC, Code 39/93/128, GS1-128, ITF-14, Codabar, QR, DataMatrix, PDF417, Aztec, China Post codes | Full 2D set |
| Read range | Hands-free 0–80 cm class | Family-class; per-model window in datasheet |
| Host interfaces | USB + RS232 | Both standard |
| Wireless | Wired unit | Presentation line is wired |
| Mounting | Counter / bay-window placement | Arrangement per model in datasheet |
| Operating temperature | Indoor commercial class | See W-series for industrial range |
| Supply terms | MOQ 1 pc · sample 1–3 days · production 10–25 days (under 5,000 pcs) | EMS standard terms |
| Warranty | 2 years | From first unit |
Family-class values shown — exact per-model figures in the datasheet; the FAE team verifies the family-top flow within 48h.
The handover bay runs its rate on the window, not on the picker.
Dispatch and handover bays in warehouses and courier stations have one continuous motion — waybill comes off the truck, crosses the station, reads at a position nobody has to lift. The R52 is the family-top presentation unit for those dense-bay windows, where the read rate is the throughput claim of the day:
- Continuous present, no lift, no pull — the family-top tuning takes the handover at its own pace — the dock's rhythm is the window's rhythm, hour after hour.
- The 2D share of the station's stream — the full set rides on the same window, from the EAN on the crate to the DataMatrix the depot's OCR line uses and the QR the courier app stamps.
- Wired bay — zero battery on the dock — a wired window in a bay of 24-7 read motion is the honest choice; no cradles in the bay, no charge of midday.
R52 FAQs
Nothing with this form factor — the R52 is the family-top presentation unit of the R series; the positions above it are the industrial-grade and fixed-mount lines, which solve a different duty class entirely.
Presented-at-window brands read at their own speed; the window's job is the rate once the label crosses the face — a bay trial over one shift gives you the honest throughput figure.
Indoor commercial class — for dock drafts and settled dust indoors the FAE helps judge; for a true open-air dock, the industrial W-series is the honest bracket, and the recommendation will say so.
Let an engineer time your R52 bays.
Send your handover rate and label mix — get a family-top check, updated datasheet and sample offer within 48h.
