R35
The R35 is the retail counter presentation scanner of the R series — the hands-free counter unit for lanes where scanning must happen without anyone picking anything up, from a counter-height window.
Key specifications
| Function | Hands-free counter 2D capture at retail lanes |
|---|---|
| Imaging engine | CMOS imager, 0.5–0.75 MP class (family standard) |
| Symbologies | All 1D plus QR, DataMatrix, PDF417, Aztec, China Post codes |
| Precision | 4 mil minimum element width class |
| Read range | Hands-free 0–80 cm class (family-class value) |
| Host interfaces | USB HID / CDC, RS232 |
| Form | Counter presentation unit — steady window, no stand needed |
| Target applications | Retail lanes, c-store counters, delivery receipt desks |
Full specification
| Parameter | Value | Note |
|---|---|---|
| Product family | EMS Biometric R-series presentation scanner | Counter tier |
| Imaging sensor | CMOS, 0.5–0.75 MP class | Family standard |
| Resolution | 4 mil class | Per-model in datasheet |
| Symbologies | EAN/UPC, Code 39/93/128, GS1-128, ITF-14, Codabar, QR, DataMatrix, PDF417, Aztec, China Post codes | Full 2D set |
| Read range | Hands-free 0–80 cm class | Family-class; per-model window in datasheet |
| Host interfaces | USB + RS232 | Both standard |
| Wireless | Wired unit | Presentation line is wired |
| Operating temperature | Indoor commercial class | See W-series for industrial range |
| Supply terms | MOQ 1 pc · sample 1–3 days · production 10–25 days (under 5,000 pcs) | EMS standard terms |
| Warranty | 2 years | From first unit |
Family-class values shown — exact per-model figures in the datasheet; the FAE team verifies lane-side flow within 48h.
Receipts and returns pass the window, not the hand.
Courier desks and receiver lines run the most repetitive read on the site: the same 1D label, thousands of times, one person doing nothing but presenting. The R35's hands-free window removes the pickup step — parcel passes, read happens, and both hands stay where the parcel actually needs them:
- The glass desk reading — the window stands at counter height and takes the waybill as it comes across, which is how a receipt desk's seconds are actually saved.
- Presentation beats handheld fumbling — a full 2D set on board covers the growing QR share without a second device on the desk.
- Counter-shaped economics — one cable, one position, MOQ 1 pc; the 2-year warranty covers a window that no one ever has to pick up, mostly because nothing is there to pick up.
R35 FAQs
Position and form: the R35 is the entry presentation unit of the R series — counter-height geometry, no stand required, the full 2D set at retail lane widths; the next rung up is the workhorse R36.
No — through-bag scanning is not a real promise; the item slides across the window face and reads from the exposed label, which is the desk workflow the unit was positioned for.
Fully counter-height — the window sits at the receipt line; send your desk sketch and the FAE team confirms the sight line against your staff's reach within 48h.
Let an engineer verify your R35 windows.
Send your desk layout and receipt flow — get a placement plan, updated datasheet and sample offer within 48h.
