X10
The X10 is the fixed-high module of the X series — the elevated-mount position for racks and station risers, where the read window hangs above the work and looks down instead of forward.
Key specifications
| Function | Elevated fixed 2D capture from rack and riser mounts |
|---|---|
| Imaging engine | CMOS imager, 0.5–0.75 MP class (family standard) |
| Symbologies | All 1D plus QR, DataMatrix, PDF417, Aztec, China Post codes |
| Precision | 4 mil minimum element width class |
| Read range | 0–80 cm class (family-class value) |
| Mounting | Elevated fixed-mount form — rack rail and riser fixture |
| Host interfaces | USB HID / CDC, RS232 |
| Target applications | Rack rail mounts, elevated checkpoints, riser-mounted windows |
Full specification
| Parameter | Value | Note |
|---|---|---|
| Product family | EMS Biometric X-series fixed module | Elevated tier |
| Imaging sensor | CMOS, 0.5–0.75 MP class | Family standard |
| Resolution | 4 mil class | Per-model in datasheet |
| Symbologies | EAN/UPC, Code 39/93/128, GS1-128, ITF-14, Codabar, QR, DataMatrix, PDF417, Aztec, China Post codes | Full 2D set |
| Read range | 0–80 cm class | Family-class; per-model curve in datasheet |
| Host interfaces | USB + RS232 | Both standard |
| Mounting | Elevated fixed-mount form | Bracket drawings in datasheet and SDK pack |
| Operating temperature | Commercial-to-industrial class | Mounting-dependent; confirm per model |
| Supply terms | MOQ 1 pc · sample 1–3 days · production 10–25 days (under 5,000 pcs) | EMS standard terms |
| Warranty | 2 years | From first unit |
Family-class values shown — exact per-model figures in the datasheet; the FAE team verifies the elevated geometry within 48h.
Some stations were designed the elevated way.
Pick-out tables, rack side stations and risers keep the scan window above the work for a reason: the tabletop belongs to the carton, and the module belongs on the rail above it. The X10 is the elevated-mount member of the X family — a fixed engine that looks down the window and keeps the surface below free for the load:
- Looking down keeps the table up — the elevated window reads the label while the carton sits flat on the table; no more flipping, no second grip.
- The rail is already there — most elevated stations have their rack rail installed; the X10's bracket geometry was designed around that reality instead of a clean-sheet mount.
- Full 2D, elevated — QR on the newest carton skins and EAN beneath both decode from the mount's angle; the family engine keeps the elevation transparent to your data.
X10 FAQs
The elevated form is designed for rack rail heights; the practical angle limit depends on label reflectivity, which is exactly what the 48h FAE pilot measures with your carton samples.
Geometry: the X10 mounts from standard vertical rails; the X10W is the angle-adapter variant that tilts the window for sloped or side-mounted positions — same engine family behind both.
The engine is a wired module — imaging is not affected by rack steel the way radio links are; the bracket geometry is the only rack consideration.
Let an engineer verify your X10 mounts.
Send your rail drawings and carton samples — get a mount plan, updated datasheet and sample offer within 48h.
